2-wire programmable transmitter
5331D
- RTD, TC, Ohm, or mV input
- Extremely high measurement accuracy
- 1.5 kVAC galvanic isolation
- Programmable sensor error value
- For DIN form B sensor head mounting
Application
- Linearized temperature measurement with Pt100...Pt1000, Ni100...Ni1000, or TC sensor.
- Conversion of linear resistance variation to a standard analog current signal, for instance from valves or Ohmic level sensors.
- Amplification of a bipolar mV signal to a standard 4...20 mA current signal.
Technical characteristics
- Within a few seconds the user can program PR5331D to measure temperatures within all ranges defined by the norms.
- The RTD and resistance inputs have cable compensation for 2-, 3- and 4-wire connection.
- Continuous check of vital stored data for safety reasons.
Mounting / installation
- For DIN form B sensor head mounting.
Data sheet & Manuals
Data sheet
- 5331D.pdf
- Latest version
Manuals
- 5331V121_UK.pdf
- 5331V120_UK.pdf
- 5331V119_UK.pdf
- 5331V118_UK.pdf
- 5331V117_UK.pdf
- 5331V116_UK.pdf
- 5331V115_UK.pdf
- 5331V114_UK.pdf
- 5331V113_UK.pdf
- 5331V112_UK.pdf
- 5331V111.pdf
- 5331V110.pdf
- 5331V109.pdf
- 5331V108.pdf
- 5331V106.pdf
- Previous versions
- Latest version
Manuals in Russian
- 5331V121_RU.pdf
- 5331V120_RU.pdf
- 5331V119_RU.pdf
- 5331V118_RU.pdf
- 5331V117_RU.pdf
- 5331V116_RU.pdf
- 5331V115_RU.pdf
- 5331V114_RU.pdf
- 5331V113_RU.pdf
- 5331V112_RU.pdf
- 5331L111_RU.pdf
- Previous versions
- Latest version
Manuals in Portuguese (Brazil)
- 5331V121_BR.pdf
- 5331V120_BR.pdf
- 5331V119_BR.pdf
- 5331V118_BR.pdf
- 5331V117_BR.pdf
- 5331V116_BR.pdf
- 5331V115_BR.pdf
- 5331V114_BR.pdf
- 5331V113_BR.pdf
- Previous versions
- Latest version
Approvals & Certificates
ATEX certificate
- 5331D_20ATEX0095X_issue0.pdf
- 5331D_06ATEX0062X_issue04.pdf
- 5331D_06ATEX0062X_issue03.pdf
- 5331D_06ATEX0062_issue02.pdf
- Previous versions
- Latest version
IECEx certificate
- 5331DIEC_200059X_issue0.pdf
- 5331DIEC_130035X_issue1.pdf
- 5331DIEC_130035X_issue0.pdf
- Previous versions
- Latest version
CSA certificate
- 533x_633x_CSA.pdf
- Latest version
FM certificate
- 53xx_633x_FM17US0013X.pdf
- 53xx_633x_FM_2D5A7.pdf
- Previous versions
- Latest version
INMETRO certificate
- INMETRO_5331_5332_5334_6331_6334_230009X_issue0.pdf
- INMETRO_5331_5332_5334_160013X_issue1.pdf
- INMETRO_5331_5334_160013X_issue0.pdf
- Previous versions
- Latest version
DNV marine certificate
- DNV_2231_41xx_51xx_53xx.pdf
- Latest version
EAC declaration
- EAC_EMC_declaration_Ex_3000_5000_6000_9000.pdf
- Latest version
EAC Ex certificate
- EAC_Ex.pdf
- Latest version
Metrology Pattern Approval (MPA), Belarus
- MPA_Belarus.pdf
- Latest version
Metrology Pattern Approval (MPA), Kazakhstan
- MPA_Kazakhstan.pdf
- Latest version
Metrology Pattern Approval (MPA), Russia
- MPA_Russia.pdf
- Latest version
Supplementary documentation
EU Declaration of Conformity
- 5331DoC_EU_106_UK.pdf
- 5331DoC_EU_105_UK.pdf
- 5331DoC_EU_104_UK.pdf
- 5331DoC_EU_103_UK.pdf
- 5331DoC_EU_102_UK.pdf
- 5331DoC_EU_101_UK.pdf
- 5331DoC_EU_100_UK.pdf
- Previous versions
- Latest version
UKCA Declaration of Conformity
- 5331DoC_UKCA_100_UK.pdf
- Latest version
CCC statement
- 5000_6000_series_CCC_statement.pdf
- Latest version
PR default configurations
- PR_default_configurations.pdf
- Latest version
Safety note
Order form
Environmental Conditions
Operating temperature | -40°C to +85°C |
Calibration temperature | 20...28°C |
Relative humidity | < 95% RH (non-cond.) |
Protection degree (encl./terminal) | IP68 / IP00 |
Mechanical specifications
Dimensions | Ø 44 x 20.2 mm |
Weight approx. | 50 g |
Wire size | 1 x 1.5 mm2 stranded wire |
Screw terminal torque | 0.4 Nm |
Vibration | IEC 60068-2-6 |
2...25 Hz | ±1.6 mm |
25...100 Hz | ±4 g |
Common specifications
Supply |
|
Supply voltage | 7.2...30 VDC |
Internal power dissipation | 25 mW…0.7 W |
Isolation voltage |
|
Isolation voltage, test / working | 1.5 kVAC / 50 VAC |
Response time |
|
Response time (programmable) | 1...60 s |
Voltage drop | 7.2 VDC |
Warm-up time | 5 min. |
Power on to stable output | 4.5 s |
Programming | Loop Link |
Signal / noise ratio | Min. 60 dB |
EEprom error check | < 3.5 s |
Accuracy | Better than 0.05% of selected range |
Signal dynamics, input | 20 bit |
Signal dynamics, output | 16 bit |
Effect of supply voltage change | < 0.005% of span / VDC |
EMC immunity influence | < ±0.5% of span |
Extended EMC immunity: NAMUR NE21, A criterion, burst | < ±1% of span |
Input specifications
Common input specifications |
|
Max. offset | 50% of selected max. value |
RTD input |
|
RTD type | Pt100, Ni100, lin. R |
Cable resistance per wire | 5 Ω (max.) |
Sensor current | Nom. 0.2 mA |
Effect of sensor cable resistance (3-/4-wire) | < 0.002 Ω / Ω |
Sensor error detection | Yes |
Linear resistance input |
|
Linear resistance min....max. | 0 Ω...5000 Ω |
TC input |
|
Thermocouple type | B, E, J, K, L, N, R, S, T, U, W3, W5, LR |
Cold junction compensation (CJC) | < ±1.0°C |
Sensor error detection | Yes |
Sensor error current: When detecting / else | Nom. 33 μA / 0 μA |
Voltage input |
|
Measurement range | -12...800 mV |
Min. measurement range (span) | 5 mV |
Input resistance | 10 MΩ |
Output specifications
Current output |
|
Signal range | 4…20 mA |
Min. signal range | 16 mA |
Load (@ current output) | ≤ (Vsupply - 7.2) / 0.023 [Ω] |
Load stability | ≤ 0.01% of span / 100 Ω |
Sensor error indication | Programmable 3.5…23 mA |
NAMUR NE43 Upscale/Downscale | 23 mA / 3.5 mA |
Common output specifications |
|
Updating time | 440 ms |
of span | = of the presently selected range |
I.S. / Ex marking
ATEX | II 1 G Ex ia IIC T6...T4 Ga, II 2 D Ex ia IIIC Db, I M1 Ex ia I Ma |
IECEx | Ex ia IIC T6...T4 Ga, Ex ia IIIC Db, Ex ia I Ma |
FM, US | Cl. I, Div. 1, Gp. A, B, C, D T4/T6; Cl. I Zone 0, AEx ia IIC T4/T6; Cl. 1, Div. 2, Gp. A, B, C, D, T4/T6 |
CSA | Cl. I, Div. 1, Gp. A, B, C, D Ex ia IIC, Ga |
INMETRO | Ex ia IIC T6...T4 Ga, Ex ia IIIC Db, Ex ia I Ma |
Observed authority requirements
EMC | 2014/30/EU & UK SI 2016/1091 |
ATEX | 2014/34/EU & UK SI 2016/1107 |
RoHS | 2011/65/EU & UK SI 2012/3032 |
EAC | TR-CU 020/2011 |
EAC Ex | TR-CU 012/2011 |
Approvals
ATEX | DEKRA 20ATEX0095X |
IECEx | DEK 20.0059X |
FM | FM17US0013X |
CSA | 1125003 |
INMETRO | DEKRA 23.0009X |
DNV Marine | TAA0000101 |
EAC Ex | RU C-DK.HA65.B.00355/19 |
